Low voltage explosion-proof lamp 30W oil-gas storage transportation station

[Applicable scope]

It is widely used in  oil drilling, oil refining, chemical industry, military industry and other dangerous environment and Marine oil platform, oil tankers and other places for general illumination lighting and assignments;

It is applicable for energy-saving reform projects and locations where are difficult to overhaul or    replace;

It is applicable for damp locations where have high protection requirements.

It is applicable for zone 1 and zone 2 in explosive gas atmosphere;

It is applicable for explosive gas atmosphere CAT. ⅡA ,ⅡB andⅡC ;

It is applicable for temperature groups T1-T6.

 [technology parameters]

Type: GMD 610

Ex-mark: Exd II CT6

Input Voltage: AC/DC 90V~265V±20% 50Hz

Rated Power：20W 30W

Power Factor：0.98

Luminous Flux of LED: 1000-3500Lm

IP Grade :   IP66

Corrosion-proof Grade：WF2

Cable Entry: G3/4" in general, suitable for cables of Φ10mm~Φ14mm

Terminal block: wires≤2.5mm²

Installation :Ceiling/Bracket/Pendant/Wall30°/Fence/Flange mounting

Operating height: 3.5~ 5m

Mounting distance : 3～5m

Net Weight：3kg

Dimension： 200mm×200mm×270mm
